It’s long-range fuel tank & wide beam, along with a modular layout that can be customised to suit your needs, make the Patrol 700 a great value, capable allrounder. In addition to plenty of storage for equipment, optional extras such as the T-Top, dive rack or deck wash provide even more functionality to this mid-sized workhorse.
6.99m
16
285l
250hp / 2*150hp
22' 11"
16
75.2 gal
250hp / 2*150hp
Key Features
5 COLOUR SCHEMES
Specifications
Overall Length
6.99m
Internal Length
5.23m
Overall Width
2.83m
Internal Width
1.64m
Dead Rise
26°
Tube Diameter
54cm
# of Air Chambers
6
Maximum Load
1280kg
Max Engine Weight (kg)
460kg
Boat only Weight
958kg*
Maximum People - Cat B
10
Maximum People - Cat C
16
Fuel Tank
285l
Max HP
250hp / 2*150hp
Engine Shaft
L Twin
XL Single
Design Category
C
Overall Length
22' 11"
Internal Length
17' 2"
Overall Width
9' 3"
Internal Width
5' 5"
Dead Rise
26°
Tube Diameter
21"
# of Air Chambers
6
Maximum Load
2822lb
Max Engine Weight (lbs)
1014lb
Boat only Weight
2111lb*
Maximum People - Cat B
10
Maximum People - Cat C
16
Fuel Tank
75.2 gal
Max HP
250hp / 2*150hp
Engine Shaft
L Twin
XL Single
Design Category
C
Standard Features
- ORCA® Hypalon or PVC tube
- Bow Cushion
- Flush mount non-return valves
- High tensile chromated & powder coated aluminum hull
- Integrated transom supports
- Self-draining deck
- Steering wheel
- Integrated under-deck fuel tank
- Lifting points and towing eyes
- Anti-slip deck
- Carbon dash
- Electrical pack for console
- Electrical pack for boat
- Transom ladder
- Bow cushion
- Welded seams (PVC)
- Tow bridle points
- Highfield dry bag
- Foot pump, oars, repair kit
Optional Equipment
- Console & seat options
- Roll Bar with ladder
- T-Top
- Suspension seat with shock
- Dive rack
- Deck wash
Choosing the Right
Tube Material:
Hypalon vs. PVC
When selecting a rigid inflatable boat (RIB), one of the most important choices is the tube material. We offer two options: Hypalon and PVC. Each has its place depending on your intended use.
PVC – Economy Option
PVC is an affordable choice suitable
for light recreational use:
Best for boats used less than 30 hours per year
Must be stored under cover when not in use
Not recommended for prolonged sun exposure or harsh environments
⚠️ Please note:
PVC is more sensitive to UV rays and chemical exposure. It may degrade faster without proper care.
Hypalon – Premium & Durable
Hypalon is the premium choice for those seeking long-term durability and ease of maintenance:
Resistant to UV and chemicals
Much easier to clean and maintain
Ideal for frequent use and demanding environments
🌴 Important:
If you plan to use your boat in tropical or high-UV regions, Hypalon is the only recommended option.
I’ve been using inflatables and RIBS for the last 30 years or so for everything from a day out with the family to a front line lifeboat, and most things in between. For the last 3 years I’ve been using a Highfield Patrol 600 for safety covers, family days out and as a media / marshal boat. She has been a revelation! Plenty of room in front and behind the console gives crews, medics and photographers space to operate, the massive lockers places to store equipment and the double spray rails the dryest ride I’ve ever experienced. Even more importantly, the feeling of robustness and safety that the high bow and hull construction gives me when the family are on board means we are happy to explore further, in comfort, then we ever have.
Andy Squirrel
